Autocycle Skin Packaging vs Blister Forming Machine Double Side Machine

Request Callback
Schedule a Demo
Ask for Price

Technical Specifications

Sl. No. MODEL STF-S&B
1 Forming Area 18” x 24”
2 Electricals & Switch Make - L&T
3 Vacuum Pump 500 LMV
4 Heat Control sunvic
5 Electric Load 10 kw.
6 Sheet Thickness 1.5 to 2 mm.
7 Material Used HIPS, PVC, ABS, PET
08 Pneumatic Cylinder Make - Janatics
9 Machine Operate Timer Make - Servotronics
10 Heating Element Tublar Air Heater - ISI Make
11 Motor 2HP Make - ABB
12 Limit Switch Make - Siemens
13 Heater Moving Pneumatic Cylinder
14 Frame Moving Pneumatic Cylinder
15 Cylinder Operation Pneumatic Valve Control
16 Machine Dimension L-96” x W-72” x H-60”
17 Machine Weight 1600 Kgs. ( Approx.)
18 Maximum Draw 100 mm.
19 Machine Doors, Frame & Parts Powder Coated
Note: Require (5 HP) Air Compressor, not supply with machine.
Delivery: 90 days after confirmation of order
